FCU - Horizontal Exposed
Sant make Fan Coil Units are for specific usage and available in Vertical or Horizontal type. The technology focuses on reform Air Delivery and efficient Heat Transfer resulting in greater cooling with low noise level and less power consumption. The unit is in compact construction encasing Fan, Coil, Motor and Air Filter
1.0 tr - 400 cfm / 1.5 tr - 600 cfm / 2.0 tr - 800 cfm / 3.0 tr - 1200 cfm.
Made up of 18 / 20g hot dip galvanized steel sheet which do resist corrosion and ensure structural integrity in all operating conditions, Casing also available with anti - condensation insulated lining.
Fan Deck -
Consists of extremely noiseless Statically and dynamically balanced forward curved centrifugal fans in aluminum or galvanized steel, directly coupled on single phase, three speed motor with permanent split capacitor and built - in thermal overload protection. Fan deck is easily removed for service and accessibility to coil.
Heat Exchanger -
Constructed in 3/8" dia expanded copper tubes with aluminum fins. The steel headers have 1/2" female connections and extra tapping for drain and air vent. The connections are on the left or right hand side looking into the air outlet of the unit. 2 row hot water coil can be added for a 4 pipe system with a chilled water or DX coil. Section to be mounted on discharge of unit.
Drain Pan -
Drain Pan is properly Insulated to ensure maximum protection against condensation and is supplied in galvanized or stainless steel with threaded drain outlet.
The 12 mm filter is made of washable synthetic polypropylene with galvanized steel or Aluminum frame and Aluminum mesh. Easy access to the filter for cleaning operation.
Applications - Residential, Offices, Hospitals, Restaurants, Schools, Shops etc.
